Topic ClosedHow To Find Area Between Contour
 Post Reply Post Reply
Author
  Topic Search Topic Search  Topic Options Topic Options
irpanch View Drop Down
Newbie
Newbie


Joined: 07.Aug.2016
Location: Indonesia
Using: AutoCAD2015
Status: Offline
Points: 2 		Direct Link To This Post Topic: How To Find Area Between Contour
    Posted: 07.Aug.2016 at 05:37
Hi

i wonder is there a tools/lisp on AutoCAD that compute area between contours?
i've try to create polygon using "BPOLY" command, but it can't create an inner area between them. since it "overlap" all the area inside first polygon.
i also have looking for GIS solution (such as ArcGIS) but can't find the solution (I stuck on converting the unit that ArcGIS provided)
any help will appreciate, thanks.


Back to Top
philippe JOSEPH View Drop Down
Senior Member
Senior Member


Joined: 14.Mar.2011
Location: France
Using: AutoCAD Mechanical 2017
Status: Offline
Points: 1494 		Direct Link To This Post Posted: 07.Aug.2016 at 09:58
Hello irpanch, you can find the area defined in the middle of the three contours by different means, for example :
-1- Use the command REGION and SUBTRACT and you will have it, but it will maybe erase the external contour.
-2- Use the command HATCH and it will fill the contour that you want without destroing the others, then you use LIST or the properties pallette ( CTRL + 1 ) to read the result.
Back to Top
